Max. machining part length 15000 mm
Max. diameter over bed 3700 mm
Max. diameter over turning support 3000 mm
Distance between centers axis and bed guideways 1940 mm
Max. load of machining part fixed between centers 150000 Kg
Max. load of machining part fixed in face plate
on first step of clamping jaw 75000 Kg
on second step of clamping jaw 50000 Kg
Max. load of machining part fixed in face plate and steady rest 150000 Kg
on first step of clamping jaw 155000 Kg
on second step of clamping jaw 130000 Kg
Face plate diameter 3050 mm
Clamping diameter on first step of clamping jaw
without extension 400 - 1700 mm
with extension 260 - 400 mm
Clamping diameter on second step of clamping jaw 1200-2500 mm
Clamping force of one hydraulic clamping jaw 35000 daN
Power of main drive motor 125 Kw
Face plate speed range (on 4 steps) 0.5 - 120 rpm
Max. main shaft torque (for 5.6 rpm) 17500 daN
Max. distance between face turning support and centers axis 1600 mm
Carriage width between inner faces of blades 520 mm
Transversal travel of tool holder saddle 1100 mm
Power of longitudinal and transversal feed motors 7.7 Kw
Longitudinal and transversal working feed range 0.1 - 400 mm/rot
Longitudinal and transversal rapid feed 3000 mm/mint
Nominal torque of feed motors 16 daN
Crest torque of feed motors 32.4 daN
Rapid speed of tail stock 2500 mm/min
Positioning speed of tail stock 50 mm/min
Cross section of square quill 750x750 mm
Max. axial load of quill center 71250 Kg
Max. radial load of quill center 75000 Kg
Angle of quill center 70°/90°
Rapid feed of quill 400 mm/min
Locking feed of quill 5 mm/min
